Non Threaded Electronic Fasteners 300 Stainless Steel Material For Printed Circuit Boards

Non - Threaded Standoffs Allow Screws Electronic Fasteners For PC Boards

Processing & Inspection Machine List.pdf

Quick Detail:

The non-threaded standoffs allow screws to be inserted through multiple layered boards for stacked assemblies. All fasteners from Polestar are identical to industry standards so that they can be fed through standard automatic insertion equipment.

Description:

Broaching-type fasteners are designed for use on printed circuit boards and on most brittle or hard materials: such as, glass laminates, epoxy or resin with paper, nylon, or canvas bases. They are also used on materials too thin or unsuitable for threading, such as acrylic and polycarbonate panels.

Since the aforementioned materials do not flow under pressure, these fasteners are designed with a knurled shank that can be pressed into a drilled hole. The shank grips the board with an interference fit by broaching its way into the panel as it is squeezed into the holes.

Hua Bao broaching fasteners can be utilized with all types of PC boards, as well as with acrylic and polycarbonate components. They install simply, quickly, and permanently for secure and reliable attachment. Their use eliminates the need for washers, lock washers, nuts, and other excess hardware.

Our broaching fasteners includes broaching nuts with permanent threads for board mounting or component attachment; threaded or unthreaded standoffs for stacking or spacing and flare mounted standoffs for greater pullout performance; threaded studs for use as solderable connectors or as permanently mounted mechanical fasteners with external threads; all-metal standoffs featuring a spring action to hold a PC board securely without screws or threaded hardware; self-expanding fasteners used in plated thru-holes in multi-layer PC Boards; and one-piece board-mount screw assemblies with captive screws for easy mounting and removal of PC boards.

Material Available for CNC parts

Technical specifications of auto lathe& cnc lathe machining parts
